Delivery Date:
02/17/2022
Department Name:
Kennebunk Fire Department
Department City / State:
Kennebunk, ME
Truck Type:
Sutphen Corporation – HS #7009
Dealer – Dingee Machine
WHEELBASE: 185”
TRAVEL HEIGHT: 9’ – 9”
TRAVEL LENGTH: 31’ – 4 ¼”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Half Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 270 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- XS QMAX-2000 GPM, Single Stage Pump
- Discharges: (1) 2 ½” Left, (1) 2 ½” Right, (1) 3” Right, (1) 2 ½” Front/Left, (1) 2 ½” Front/Right, (1) 2 ½” Right/Front Hosebed, (1) 3” Deck Gun
- 1,000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: Hale SmartFoam 2.1 A
BODY: Sutphen
- 3/16” Extruded Aluminum
- ROM Roll-up Compartment Doors
- 200 cu. ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: PA-01 RES 31/53 Electric Ladder Rack
ADDITIONAL EQUIPMENT:
- 18” Formed Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Two Cameras
- Intercom System: Firecom Two Position
- Zico Electric Ladder Rack
- Roto Ray Warning Light
- Whelen Freedom 72” LED Lightbar
- Whelen PFH2 Brow Light
- Whelen 900 Scene Lights
