Delivery Date:
04/03/2023
Department Name:
Hilton-Parma Fire District
Department City / State:
Hilton, NY
Truck Type:
Sutphen Corporation – HS #7257
Dealer – Herb Fire
WHEELBASE: 204”
TRAVEL HEIGHT: 9’ – 8”
TRAVEL LENGTH: 33′ – 0 ½”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with 10” Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension: 20,000 lbs.
- Rear Axle and Suspension: 27,000 lbs.
- Engine: Cummins L 9, 380HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Left Rear, (1) 2 ½” Pipe Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
- Crosslays: (1) 2 ½”, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
- 750-Gallon Water Tank
BODY: Sutphen
- Huckbolt #304 Stainless Steel
- Amdor Roll-Up Compartment Doors
- 178 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 1200A 28’ 2-Section & 875-A 16’ Roof & 10’ Folding
- Body: PS-12 RES 50/47 Low Right (BRKT/Electric Rack)
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Generator: Smart Power 8KW
- Hannay Electric Cord Reel, 200’ (1)
- Whelen Freedom IV 72” LED Light Bar
- Whelen PFH2 LED Brow Lights (2)
- Whelen McFled Beacons
- FireTech FT-SL-30-W Tele Lights
- FireTech FT-MB2.15 CPREC LED Scene Lights
