Delivery Date:
04/12/2019
Department Name:
Halfmoon Fire Department
Department City / State:
Waterford, NY

WHEEL BASE: 208”

TRAVEL HEIGHT: 9’ – 5”

TRAVEL LENGTH: 33’ – 10”

CHASSIS:             Sutphen Monarch Heavy Duty-Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM Single Stage
  • Discharges: (1) 2 ½” Left, (1) 4” Right, (1) 3” Right, (2) 3” Pipe to Right Rear, (2) 3” Pipe to Left Rear, (1) 3” Front/Left of Main Hosebed, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • No Crosslays
  • 995-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Monitor: TFT XFC-42 Crossfire w/ Safety Flow, Quad Stack Tips and Stream Shaper

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Doors
  • Over 173” cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package (1200A 28’ 2-Section, 875A 16’ Roof, 585A 10’ Folding)

ADDITIONAL EQUIPMENT:

  • Voyager 3, Split Screen Camera System
  • Federal Q2B Siren, Flush Grille Mount
  • Whelen Freedom (14) LED Lightbar
  • FRC Spectra 12V LED Brow
  • FRC Spectra 240V LED Tele
  • FRC Spectra 12V LED Scene
  • 10KW Harrison Hydraulic Generator
  • Hannay Electric Cord Reel, 150’ (2)
  • 24” Polished Stainless Steel Bumper Extension
