Delivery Date:
05/11/2019
Department Name:
Greenwood Fire Department
Department City / State:
Greenwood, AR

WHEEL BASE: 215”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 33’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper Discharge, (1) 3” Deck Gun
  • Speedlays: (2) 2” w/ 1 ½” Swivel
  • Monitor: Akron 3423 Apollo
  • 1,500-Gallon Water Tank
  • 30-Gallon Foam Tank
  • FoamPro 2001

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • 193 cu. ft. Total Compartment Space
  • Alco-Lite (PEL-24 24’ 2-Section and PRL-14 14’ Roof and 10’ Folding)

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Flush Grille Mount
  • Ziamatic Quic-Lift Electric Ladder Rack
  • FRC, Inview True View Camera System
  • Whelen Freedom LED Lightbar
  • Whelen M9 Scene Lights
  • FRC Spectra Brow Light
  • FRC Spectra Telescopic Lights
  • Triple Air Bottle Compartments (3)
