Delivery Date:
05/11/2019
Department Name:
Eastampton Fire Department
Department City / State:
Eastampton, NJ

WHEEL BASE: 232”

TRAVEL HEIGHT: 10’ – 3”

TRAVEL LENGTH: 35’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 15” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 270 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 3” Right, (1) 3” Pipe to Left Rear, (1) 2” Right/Front Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (3) 2” Valve-Piping 1 ½” Swivel
  • 1,000-Gallon Water Tank
  • 25-Gallon Foam Tank
  • FoamPro 2001, 2.6 GPM

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • Over 311 cu. ft. Total Compartment Space
  • Ladder Chute under Hose Bed

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper Extension
  • Camera System, Safety Vision SV-CLD0-70
  • Hannay Electric Cord Reel, 175’ (2)
  • Federal Q2B Siren, Flush Grille Mount
  • Whelen 21” Freedom Lightbars (3)
  • Whelen 600 Series Warning Lights (8)
  • FR Spectra Brow Light
  • FR Spectra Tele Lights (2)
  • FR Spectra Scene Lights (4)
  • Ziamatic Quic-Lift Electric Ladder Rack
