Delivery Date:
05/12/2025
Department Name:
Cocoa Beach Fire Department
Department City / State:
Cocoa Beach, FL
Truck Type:
Dealer – South Florida Emergency Vehicles
WHEELBASE: 197”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 32’ – 4”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10-Inch Raised Roof
- Four-Door, Six-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 6, EVS3000
PUMP: Hale
- QMAX-1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, 2” Plumbing, (1) 3” Deck Gun
- Crosslays: (2) 2” w/ 1 ½” Swivel
- 1000-Gallon Water Tank
- 30-Gallon Foam Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Mixed ROM Roll-Up and Hinged Compartment Doors
- Nearly 300 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: G9 – Alum 40/51 Ladders Thru Tank
ADDITIONAL EQUIPMENT:
- 18” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Single Camera (Wired)
- FRC Spectra 12V Brow
- Whelen Freedom IV 72” LED Lightbar (12 Module)
- Whelen 900 12V Scene
- FireTech 12V Work Light
