Delivery Date:
07/22/2021
Department Name:
Cashtown VFD
Department City / State:
Cashtown, PA

Sutphen Corporation – HS #6808

Dealer – Lawver Fire Apparatus

WHEELBASE: 214”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 33’ – 11 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 1 ½” Right, (1) 2 ½” Pipe to Left Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 2 ½” Front Bumper
  • Speedlay: (2) 1 ½” w/ Lift Out Tray
  • 1,000-Gallon Water Tank



BODY:                  Sutphen

  • Hinged Compartment Doors
  • Over 250 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Compliment: (900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding)
  • Body: PA-12 RES 43/53 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera
  • Generator: Smart Power 6KW
  • Hannay Electric Cord Reel, 175’ (1)
  • Whelen Freedom IV Rota-Beam 72” LED Lightbar
  • Whelen M9 Warning Lights
  • FRC Spectra LED Brow Light
  • FRC Spectra LED Scene Lights
  • Roto-Ray Warning Light
