Delivery Date:
04/14/2019
Department Name:
Bridgeport Fire Department
Department City / State:
Bridgeport, NY

Sutphen Corporation – HS #6221

Dealer – Vander Molen Fire Apparatus Sales and Service

WHEEL BASE: 217”

TRAVEL HEIGHT: 10′ – 2”

TRAVEL LENGTH: 32’ – 11”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1250 GPM, Single Stage Pump
  • Discharges: (1) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 3” Pipe to Left Rear, (1) 3” Deck Gun
  • Crosslays: (2) 2” w/ 1 ½” Swivel
  • Monitor: Akron 3440 Deck Master Electric Deck Gun with Akron 1578 Sabre Master Nozzle
  • 1,000-Gallon Water Tank
  • 40-Gallon Foam Tank
  • Williams ATP 500 Foam System – Class A

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • Over 306 cu. ft. Total Compartment Space
  • Alco-Lite Ladders (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chute

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel Bumper
  • 10KW Harrison Generator
  • Hannay Electric Cord Reel, 150’ (2)
  • Whelen 72” Freedom Lightbar
  • Whelen 600 Series Warning Lights (12)
  • Akron Scene Star Brow Light
  • Akron Scene Star Tele Lights
  • Camera System, Voyager 3
