Delivery Date:
02/26/2020
Department Name:
Bloomingdale Fire Department
Department City / State:
Bloomingdale, IL

WHEELBASE: 212”

TRAVEL HEIGHT: 10’ – 1”

TRAVEL LENGTH: 33’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) 3” Deck Gun
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank
  • FoamPro 2002

BODY:                  Sutphen

  • 3/16” Extruded Aluminum Mounting Plate
  • Amdor Hinged Compartment Doors
  • 8 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-28 28’ 2-Section Extension & PRL-16 16’ Roof & 10’ Folding)
  • Body: Stainless Steel Low Rgt, Elec Rack

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Air Bottle Compartments (7)
  • Whelen M6 Warning Lights
  • Whelen Freedom 21” Lightbar
  • Whelen M9 Scene Lights
  • Mars 888 LED Warning Lights
