Department Name:
Frankford Township Fire Department
Department City / State:
Augusta, NJ

Dealer – Signal 1 Fire Equipment

WHEELBASE: 211 1/16”

TRAVEL HEIGHT: 11’

TRAVEL LENGTH: 30′ – 4”

CHASSIS:             Kenworth T880-2DR Commercial Chassis

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 46,000 lbs.
  • Engine: Cummins X 15, 500HP
  • Alternator: For Commercial Chassis
  • Transmission: EVS 4500

PUMP:                  Hale

  • Side Kick DSD, 1250 GPM, PTO
  • Discharge: (2) 2 ½” Left, (1) 2 ½” Right, (1) 4” Left Rear, (1) 2 ½” Left Hosebed, (1) 2” Left Hosebed
  • 3,500-Gallon Water Tank

BODY:                  Sutphen

  • Huckbolted #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • 67 cu. ft. Total Compartment Space
  • Body: SWT-05C STS Wet Side Tanker Tandem, Integrated Pump

ADDITIONAL EQUIPMENT:

  • Federal Q2B Siren, Front Bumper Mount
  • Camera System: Brigade, Single Camera
  • Zico Porta Tank Rack w/ 3,500 Gallon Porta Tank
  • Whelen 56” Justice Lightbar
  • Whelen M9 Scene Lights
  • Whelen 600 Warning Lights
