Delivery Date:
05/01/2018
Department Name:
Wolfhurst Volunteer Fire Department
Department City / State:
Bridgeport, OH

WHEEL BASE: 215”

TRAVEL HEIGHT: 9’ 10”

TRAVEL LENGTH: 33′ 10”

CHASSIS:              Sutphen 62” Cab with 10” half raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 18,000 Lbs.
  • Rear Axle and Suspension: 24,000 Lbs.
  • Engine: Cummins L 9 450HP
  • Alternator: Niehoff 360 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX-2000 GPM Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Left Rear, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing
  • 750 Gallon Water Tank

BODY:                   Sutphen

  • 222 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Hosebed Supports
  • Park Brake Release
  • Mirror Velvac, West Coast Style Stainless Steel, Heated & Remote
  • Auxiliary Cab Steps, Alum Set of 4
  • Intake Pressure Control Akron Style 53
  • 5” Crosslay in Dunnage
  • Crosslay Cover Hinged Treadplate with Vinyl Sides
