Delivery Date:
08/01/2018
Department Name:
Whitehall Division of Fire
Department City / State:
Whitehall, OH

WHEEL BASE: 176”

TRAVEL HEIGHT: 9′-8″ ±2″

TRAVEL LENGTH: 31’

CHASSIS:              Sutphen 62” Cab with 10” half raised roof

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension: 18,000 Lbs.
  • Rear Axle and Suspension: 24,000 Lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX-1500 6” Suction Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Valve 2.5” Pipe to Left Rear, 3” Deck Gun
  • 750 Gallon Water Tank
  • 20 Gallon Foam Cell

BODY:                   Sutphen

  • 7 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • 12V Power Strip Mounted on AC Unit
  • Remove Hub Stainless Cover
  • Manual Cab Tilt Release In Place of Air Operated
  • Magnetic Radio Mic Holder
  • Storage Compartment Custom Design
  • Front Overhead Storage, Front Raised Roof w/Net, Custom size
  • One 2” Crosslay with 1.5” Swival
  • 1” Lip Around the Bottom of L2 Compartment
  • 12 Volt Compartment Heater
  • 1” Lip Around the Bottom of the R2 Compartment
  • Cord Reel and miscellaneous Storage Compartment with 1 Lid
  • Amdoor Brand Roll Up for A1
  • Custom Hosebed Notching
  • Mounting of Reel in Upper Storage Right Front of Hosebed Compartment
