Delivery Date:
12/06/2022
Department Name:
Elysburg Fire Department
Department City / State:
Elysburg, PA

Sutphen Corporation – HS #7196

Dealer – Signal 1 Fire Equipment

WHEELBASE: 196”

TRAVEL HEIGHT: 10’ – 10”

TRAVEL LENGTH: 32′ – 9 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension: 23,000 lbs.
  • Rear Axle and Suspension: 48,000 lbs.
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville 420 AMP
  • Transmission: Allison Gen 5, EVS4500

PUMP:                  Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (3) 2” w/ 1 ½” Swivel
  • 2,500-Gallon Water Tank

BODY:                  Sutphen

  • Huckbolted #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • 97 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: 24’ 2-Section & 14’ Roof & 10’ Folding
  • Body: SWT-04A STS Wet Side Tanker, Tandem

ADDITIONAL EQUIPMENT:

  • 18” Formed Steel Channel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade, Single Camera
  • Zico Electric Porta Tank Rack w/ 2100-Gallon Porta Tank
  • FireTech 3-Piece Brow Light
  • Whelen 21” Freedom Lightbars (3)
  • Mars Lights (2)
  • Roto-Ray Warning Light
  • FRC Spectra Scene Lights
  • FireTech Double Stack Mini Brow
  • Whelen 36” Traffic Advisor
