Delivery Date:
03/04/2020
Department Name:
Wixom Fire Department
Department City / State:
WIxom, MI

WHEELBASE: 210”

TRAVEL HEIGHT: 10’ – 5”

TRAVEL LENGTH: 34’

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 15” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • 500 GPM, Single Stage Pump
  • Discharges: (1) 2 ½” Streetside, (1) Booster Reel
  • 300-Gallon Water Tank

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors

ADDITIONAL EQUIPMENT:

  • 12” Formed Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Rear View Camera
  • Onan Hydraulic-Driven Generator
  • (3) Air Bottle Compartments
  • Whelen PFH2 12V LED Brow Light
  • Whelen Freedom IV LED Lightbar
  • Whelen 900 12V Scene Lights
