Delivery Date:
06/01/2018
Department Name:
Springfield Township Fire Department
Department City / State:
New Springfield, OH

WHEEL BASE: 185”

TRAVEL HEIGHT: 9′-10″

TRAVEL LENGTH: 31′-10″

CHASSIS:              Sutphen 62” cab with 10” half raised roof

  • Four-Door, Six Person Cab
  • Front Axle and Suspension: 19,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9 400HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • QMAX-1500 GPM Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Left Rear, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
  • 750 Gallon Water Tank

BODY:                   Sutphen

  • 246 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Pump Primer Trident Auto Prime
  • Triple Bottle Wheelwell Storage
  • Oil Dry Hopper
  • Ladder Chute Modification
  • Grip Strut Cab Steps
  • Installation of Customer Antennas
  • Glove Holders
  • Additional Door Adjar Indicator
  • Streamlight Fire Vulcan Hand light W/12 Volt Vehicle Charger Rack
  • Pressure Control Century Pressure Governor w/Twister
