Delivery Date:
02/15/2024
Department Name:
Chevron California
Department City / State:
El Segundo, CA

WHEELBASE: 277 ½”

TRAVEL HEIGHT: 12’

TRAVEL LENGTH: 48’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 56” Extended Cab w/ a Flat Roof

  • Four-Door, Four-Person Cab
  • 13” Double Domex Frame Rails
  • Front Axle and Suspension 25,500 lbs
  • Rear Axle and Suspension 62,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Waterous

  • CRU-2C21 3500 GPM
  • Discharges: (3) 6” LDH Right Side; (1) 3” Right Side (Foam Capable); (1) 2 ½” Right Side (Foam Concentrate Only); (1) 2.5” Left Side (Foam Concentrate Only)
  • Crosslays: 2” Valve-Piping 1 ½” Swivel (Foam Capable)
  • 300-Gallon Foam Tank

BODY:                  Sutphen

  • Huckbolt #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 225 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 16’ R, 24’ 2-Section
  • Body: SP110-3 – Left High / Right Intermed

ADDITIONAL EQUIPMENT:

  • 12” Formed Steel Channel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FireCom 5100D, Single Radio, 4-Position
  • Generator: Smart Power, 10KW
  • Hannay Electric Cord Reel, 150’ (1)
  • Camera System: Brigade, Backeye 360 Camera System
  • Whelen Freedom IV 72” Light Bar
  • 12V FR Spectra Brow Light
  • Rigid D2 Aerial Spotlights
  • Whelen 600 Warning Light
  • 240V FR Spectra Tele Light

MONITOR:

  • Driver Side Monitor: DS, TFT Electric Monsoon and Master Stream Nozzle
  • Officer Side Monitor: TFT Electric Monsoon and Master Stream Nozzle
