Delivery Date:
09/23/2021
Department Name:
Thornwood Fire District
Department City / State:
Thornwood, NY

Sutphen Corporation – HS #6782

Dealer – Mike Myers

WHEELBASE: 236”

TRAVEL HEIGHT: 11’ – 6”

TRAVEL LENGTH: 46’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ 10” Raised Roof

  • Four-Door, Eight-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4500

PUMP:                 Waterous

  • CSU-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 2 ½” Right, (1) 4” Right
  • Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (1) 2” Crosslays w/ 1 ½” Swivel

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • Combination Hinged and ROM Roll-up Compartment Doors, Painted
  • Over 305 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Compliment: 117’: 14’, 16’, 18’, 24’ 2-Section, 35’ 2-Section & 10’ Folding
  • Body: SPH-3, LEFT 56″ H / RIGHT 56″H

ADDITIONAL EQUIPMENT:

  • 12” Formed Steel Channel Painted Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade Backeye 360
  • Intercom System: FRC ACT 2-Station
  • Hannay Electric Cord Reel, 175’ (1)
  • Generator: 10KW Harrison HYD
  • Whelen Freedom IV 81” Light Bar
  • Whelen Pioneer 12V Brow Light
  • Whelen Mini Freedom IV 23.25” Lightbar
  • Whelen Pioneer 120V Tele Lights
  • Rigid D2 Work Lights

MONITORS:

  • Driver Side Monitor: Akron 3473 Gemini Manual 1000 GPM
  • Driver Side Nozzle: TFT MST-4NJ Stacked Tips w/ XF-SS10 Stream Straightener
  • Officer Side Monitor: Akron 3473 Gemini Manual 1000 GPM
  • Officer Side Nozzle: TFT MST-4NJ Stacked Tips w/ XF-SS10 Stream Straightener
