Delivery Date:
05/13/2021
Department Name:
Greencastle Fire Department
Department City / State:
Greencastle, IN

Sutphen Corporation – HS #6767

Dealer – Herb Fire Equipment

WHEELBASE: 230”

TRAVEL HEIGHT: 11’ – 6”

TRAVEL LENGTH: 46’ – 3”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 56” Cab w/ Flat Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails, Tandem Axle – Aerial (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12 600HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison EVS4000

PUMP:                 Hale

  • QMAX-1500 GPM 6” Suction, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (2) 2 ½” Right
  • Crosslay: (1) 2 ½”, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
  • 300-Gallon Water Tank

BODY:                  Sutphen

  • Mix Amdor Roll Up and Hinged Compartment Doors
  • Over 280 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: 115’: 14’, 16’, 16’, 24’-2Sec, 35’-2Sec & 10’F
  • Body: SPH-3, LEFT 56″ H / RIGHT 56″H

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC Inview Trueview, Two Camera
  • Intercom System: FRC IC301 3-Station
  • Hannay Electric Cord Reel, 175’ (1)
  • Generator: Smart Power 10KW
  • Whelen Freedom IV 72” LED Lightbars
  • Whelen M9V2
  • Whelen LED Traffic Advisor
  • FireTech FT-B-46-W Screen Lights
  • FR 240V Spectra Scene Light
  • FR 240V Spectra Tele Lights

MONITOR:

  • Officer Side Monitor: Akron 3483 Stream Master 2, Manual 1250 GPM
  • Driver Side Monitor: Akron 3482 Stream Master2, Electric, 1250 GPM w/ Akron 5177 Electric Nozzle
