Delivery Date:
10/23/2023
Department Name:
Delta Township Fire Department
Department City / State:
Lansing, MI

Dealer – Apollo Fire Apparatus Sales and Service

WHEELBASE: 247”

TRAVEL HEIGHT: 11’ – 6”

TRAVEL LENGTH: 48’ – 6”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10” Raise Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12, 500HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Front Bumper
  • Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
  • 300-Gallon Water Tank

BODY:                  Sutphen

  • Huckbolt #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 280 cu ft. Total Compartment Space
  • Alco-Lite Ladder Package: 14’, 16’, 16’, 24’ 2-Section, 35’ 2-Section & 10’ F
  • Body: SPH-3, Left 56” H / Right 56” H

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC, Act 3-Station
  • Hannay Electric Cord Reel, 175’ (1)
  • Generator: Smart Power, 10KW
  • Camera System: Brigade, Backeye 360 Camera System

MONITOR:

  • Driver Side Monitor: TFT Monsoon EC, Elec, w/ Elec VUM, (2) Panel Controllers Includes TFT Master Stream 1250 GPM Elec Nozzle
  • Officer Side Monitor: TFT Monsoon, Manual 2000 GPM w/ Manual VUM, Y4-MP1A
  • Officer Side Nozzle: TFT MST-4NJ Stacked Tips w/ XF-SS10-NN Stream Straightener
