Delivery Date:
10/10/2023
Department Name:
US Steel
Department City / State:
Gary, IN
Truck Type:

Dealer –  Herb Fire

WHEELBASE: 232”

TRAVEL HEIGHT: 10 – 0 ½”

TRAVEL LENGTH: 42’ – 3”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a Flat Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville, 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side Body, (1) 1 ½” Front Bumper
  • Monitor: TFT Y5-E11A-L Typhoon Electric w/ M-ERP-1500 Nozzle
  • Crosslays: (2) 2” Valve-Piping w/ 1 ½” Swivel
  • 500-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Foam Pro 2002, 5.0 GPM

BODY:                  Sutphen

  • Huckbolt #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 210 cu ft. Total Compartment Space
  • Duo-Safety Ladder Package: 24’, 16’ & 10’ F
  • Body: SAA-4, Left High / Right Intermed / Trans

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Intercom System: FRC ACT 2-Station
  • Camera System: Voyager 2
  • Ziamatic Quic-Lift Electric Ladder Rack
  • Whelen Freedom 4 Lightbar
  • FRC Spectra 12V 28K LED Scene Light
  • FRC Spectra 900 12V LED Scene Light
  • Whelen PELCC Lights
  • Whelen L31 LED Beacons
  • FireTech 12V LED Boom Spotlights
