Delivery Date:
05/25/2019
Department Name:
Sterling Fire Department
Department City / State:
Sterling, CT

WHEEL BASE: 221”

TRAVEL HEIGHT: 10’ – 9 ¼”

TRAVEL LENGTH: 41’ – 10 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins ISX12, 455 HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP                   Hale

  • QMAX-2000 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side
  • Monitors: (1) Elkhart TFT Y4-M15A Manual Monitor with M-RP1250 Manual Nozzle & Streamshaper, (1) TFT Y4-E15A Monsoon Electric RC Monitor w/ M-ERP 1250 Electric Nozzle and Streamshaper
  • Crosslays: (2) 2” Valve-Piping 1 ½”
  • 500-Gallon Water Tank
  • 25-Gallon Foam Tank
  • Hale Smartfoam 3.3

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 193 cu. ft. Total Compartment Space
  • Alco-Lite Quint Ladder Compliment (85’: 16’R, 24’ 2-Section, 35’ 3-Section & 10’F)
  • SAA-3 Left High/Right Intermed

ADDITIONAL EQUIPMENT

  • 6” Polished Stainless Steel Bumper Extension
  • Voyager 3, Camera System
  • Federal Q2B Siren
  • 6KW Smart Power Generator
  • Hannay Electric Cord Reel, 175’ (1)
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom 4 Lightbar
  • Whelen PFP1 12V LED Brow Lights (2)
  • LED Marker Lights
