Delivery Date:
06/21/2019
Department Name:
Rockwood VFD
Department City / State:
Rockwood, TN

Sutphen Corporation – HS #6339

WHEEL BASE: 221”

TRAVEL HEIGHT: 10′ – 9 ¼”

TRAVEL LENGTH: 42’ – 11 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Eight-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
  • Monitor: TFT Y4-M15A Monsoon 1250 GPM Manual Monitor w/ M-RP1250 Nozzle (1) TFT Y5-E15A Monsoon 1250 GPM Electric Monitor w/ M-ERP1250 Nozzle
  • Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
  • 500-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Hale SmartFoam 2.1

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 193 cu. ft. Total Compartment Space
  • Alco-Lite Quint Ladder Compliment (85’: 16’ Roof, 24’ 2-Section, 35’ 3-Section & 10’ Folding)
  • SAA-3: Left High / Right Intermed

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper Extension
  • FRC Inview Trueview, Camera System
  • 10KW Smart Power Generator
  • Hannay Electric Cord Reel, 150’ (1)
  • Pike Pole Storage Tubes (3)
  • Federal Q2B Siren, Flush Grille Mount
  • FRC Spectra LED Brow Light
  • GoLight Stryker LED
  • Whelen Justice 62” Lightbar
  • FRC Spectra 20K 12V Under Bucket Scene Light
  • Oil Dry Hopper
