Delivery Date:
10/15/2020
Department Name:
Melbourne Fire Department
Department City / State:
Melbourne, FL
Truck Type:

Sutphen Corporation – HS #6721

Dealer – South Florida Emergency Vehicles

WHEELBASE: 232”

TRAVEL HEIGHT: 10’ – 9 ¼”

TRAVEL LENGTH: 44’ – 10 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
  • Crosslay: (2) 2” Valve-Piping 1 ½” Swivel
  • 300-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • Over 190 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (85’: 16’ Roof, 24’ 2-Section, 35’ 3-Section & 10’ Folding)
  • Folding Ladder Chute and Dual Pike Pole Storage in Highside Hosebed
  • Body: SAA-4, Left High/Right Intermed/Trans

ADDITIONAL EQUIPMENT:

  • 30” Polished Stainless Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade 360
  • Generator: Energizer Inverter 3200 Remote Start
  • Intercom System: FRC ACT 2-Station
  • Whelen Freedom 4 Lightbar
  • Whelen PFH2 12V LED Brow Light
  • Whelen PFH2 12V Telescoping Scene Light
  • Whelen PFP2AC 120V LED Tele-Light

MONITORS:

  • Monitor: (2) Akron Manual Stream Master 2 w/ Streamshapers & Smooth Bore Stacked Tips
  • Nozzle: Akromatic 1250 Master Stream (1)
