Delivery Date:
10/22/2019
Department Name:
Oswego Fire Department
Department City / State:
Oswgeo, NY

Sutphen Corporation – HS #6452

WHEEL BASE: 232”

TRAVEL HEIGHT: 10’-0 ½”

TRAVEL LENGTH: 42’-4”

CHASSIS:             Sutphen Monarch Heavy Duty-Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (2) 1 ½” Front Bumper
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • Monitor: Akron 3480 Stream Master2 Elec RF w/ 5178 Nozzle
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • Amdor Roll-Up Compartment Doors
  • Over 192 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Compliment (109’: 10’F, 10’F, 16R’, 24’ 2-Section & 35’ 3-Section)
  • SAAA-4, Left High / Right Intermed / Trans

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel, Painted Bumper Extension
  • Camera System, FRC, Inview Trueview, Single Camera
  • Hannay Electric Cord Reel, 150’ (1)
  • Ziamatic Extinguisher Cradle in Hydraulic Compartment (4)
  • Speedy Dry Hopper
  • Pike Pole Storage Tubes (6)
  • 8KW Harrison Generator
  • Federal Q2B Siren, Grille Mount
  • Roto-Ray Warning Light
  • FRC Spectra 12V LED Brow Light
  • FRC Spectra 240V LED Scene Light
  • Whelen Freedom 4 Lightbar
  • Whelen M9 12V LED Scene Lights
