Delivery Date:
02/20/2020
Department Name:
Franklin Fire Department
Department City / State:
Franklin, TN

WHEELBASE: 214”

TRAVEL HEIGHT: 10’ – 4”

TRAVEL LENGTH: 34’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 15” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins X 12, 455 HP
  • Alternator: Idle Pro, 420 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Left Rear, (1) ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Akron Foam Supply System w/ Flush

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • 5 cu. ft. Total Compartment Space
  • Duo-Safety Ladder Package (900A 24’ 2-Section & 775A 14’ Roof & 10’ Folding)
  • Fully Enclosed Ladder Chutes
  • Body: PA-12 – Res 43/53 Ladders Through Tank

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel, Bumper Extension
  • Siren, Federal Q2B Siren, Grille Mount
  • Rear Vision Camera
  • FRC Spectra 12V LED Brow Lights
  • FR Spectra 12V scene Light
  • Whelen LED Lightbar
  • Whelen M9V Red Warning/Scene Lights
