Delivery Date:
08/12/2018
Department Name:
Findlay Fire Department
Department City / State:
Findlay, Ohio

WHEEL BASE: 196”

TRAVEL HEIGHT: 9’-10”

TRAVEL LENGTH: 32’-3”

CHASSIS:             Sutphen 73” cab with half 10” raised roof

  • Four-Door, Five-Person Cab
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 380 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

Pump:                  Hale

  • QMAX-1500 GPM
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, 1 ½” Front Bumper, (1) 3” Deck Gun
  • 750-Gallon Water Tank
  • Hale SmartFoam 2.1
  • 20-Gallon Foam Tank

BODY:                  Sutphen

  • Aluminum
  • Rom Roll-Up Doors
  • 270 cu. ft. Total Compartment Space
  • Ladder Chute

OPTIONAL EQUIPMENT:

  • Hannay Cord Reel, 200’
  • Scene Lights, Whelen M9 LED
  • Federal Q2B
  • 18” Bumper
  • Warning Lights, Whelen
