Delivery Date:
02/21/2020
Department Name:
Dearborn Fire Rescue
Department City / State:
Dearborn, MI

WHEELBASE: 185”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 32’ – 1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Single Frame Rails (50K PSI)
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” w/ 1 ½” Swivel
  • 500-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Foamlogix with Intelli-tank Gauge

BODY:                  Sutphen

  • ROM Roll-Up Compartment Doors
  • 3 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Fully Enclosed Ladder Chutes
  • Body: S2 – Alum 43/53 Ladder chute

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel, Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Rear Vision Camera
  • Whelen PFH2 12V Brow Light
  • Whelen 900 Telescopic Lights
  • Whelen Freedom LED Lightbar
  • Whelen M9V Red Warning/Scene Lights
