Delivery Date:
12/18/2019
Department Name:
Junior Volunteer Fire Department
Department City / State:
Junior, WV

Sutphen Corporation – HS #6156

Dealer – Heritage Fire Equipment

WHEEL BASE: 219”

TRAVEL HEIGHT: 10’-4”

TRAVEL LENGTH: 35’-5”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 15” Raised Roof

  • Four Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 50,000 lbs
  • Engine: Cummins X 15, 600 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS4000

PUMP:                 Waterous

  • CSU-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Pipe to Left Rear, (1) 2 ½” Front/Right of Main Hosebed, (1) 3” Deck Gun
  • Monitor: TFT Monsoon, Manual 1500 GPM
  • Crosslays: (2) 2”, 1 ½” Swivel
  • 3,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Doors
  • 6 cu. ft. Total Compartment Space
  • Alco-Lite PEL-24 (24 2-Section and PRL-14 14’ Roof and 10’ Folding

OPTIONAL EQUIPMENT:

  • 12” Bumper Extension
  • Voyager Camera System
  • Ladder Chute
  • Federal Q2B Siren
  • Roto-Ray
  • Whelen Freedom IV LED Light Bar
  • FRC Spectra 12V LED Brow
