Delivery Date:
07/28/2020
Department Name:
Shiloh Danieltown Fire Department
Department City / State:
Forest City, NC

Sutphen Corporation – HS #6589

Dealer – Stevens Fire Equipment

WHEELBASE: 175”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 31’ – 1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 18,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 270 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • DSD-1,250 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (2) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (2) 2” Valve-Piping w/ 1 ½” Swivel
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • AMDOR Roll-Up Compartment Doors
  • 246 Cu. Ft. Base Compartment Space
  • Alco-Lite Ladder Package (24’ 2-Section, 14’ Roof and 10’ Folding)
  • Body: G9-Alum 40/51

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless-Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview
  • 8KW Smart Power Generator
  • 4 Bottle Compartments
  • FRC Spectra LED Brow Light
  • Whelen Freedom IV Lightbar
  • Whelen 600 LED Red Lights
  • Whelen L31 LED Red Beacons
  • Whelen Ion LED Red Lights
