Delivery Date:
03/15/2021
Department Name:
Salem Fire Department
Department City / State:
Salem, OH

Sutphen Corporation – HS # 6785

Dealer – Herb Fire

WHEELBASE: 196”

TRAVEL HEIGHT: 10’

TRAVEL LENGTH: 32’-8”

CHASSIS:              Sutphen Monarch Heavy-Duty Custom Chassis, 73” extended cab with 10” raised roof

  • Four-Door, Four-Person Cab
  • 10” Double Rails, Single Axle (110K PSI)
  • Front Suspension 20,000 lbs.
  • Rear Suspension 27,000lbs.
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • XS QMAX-2,000 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper w/ 2 ½” Plumbing, (1) 3” Deck Gun
  • Crosslays: (1) 2 ½” w/ Swivels and Poly Lift-Out Trays
  • Speedlays: (2) 2” w/ Swivels and Poly Lift-Out Trays
  • 1000-Gallon Water Tank
  • 20 Gallon Foam Tank

BODY:                   Sutphen

  • Aluminum 40/51
  • ROM Roll-Up Compartment Doors Painted
  • 294 cu. ft. Total Compartment Space
  • Body: Custom Pumper G9

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless-Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Whelen Freedom LED Light Bar
  • Firetech Spectra Brow Light
  • Whelen 900 Red LED
  • Will-Burt Light Tower
