Delivery Date:
07/18/2019
Department Name:
Rennerdale VFD
Department City / State:
Carnegie, PA

WHEEL BASE: 196”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 33’ – 1”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear Hosebed Discharge, (1) 2 ½” Right Rear Hosebed Discharge, (1) 3” Deck Gun
  • Crosslays: (1) 2 ½” Crosslay & (2) 2” Speedlays w/ 1 ½” Swivel & Poly Lift-Out Tray
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • 294 cu. ft. Total Compartment Space
  • Alco-Lite (PEL-24 24’ 2-Section and PRL-14 14’ Roof and 10’ Folding)
  • Ladder Chute

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper
  • FRC, Inview Trueview Camera System
  • Hannay Electric Cord Reel, 150’ (1)
  • 10KW Smart Power Generator
  • Federal Q2B Siren, Grille Mount
  • Oil Dry Hopper w/ SCBA Cylinder Compt. (2 Triple, 1 Single)
  • FRC Spectra Brow Lights (2)
  • Hi-Viz Guardian Elite LED Scene Lights
  • Whelen Traffic Advisor
  • Whelen 900 Red LEDs
