Delivery Date:
02/27/2020
Department Name:
Norwich Township Fire Department
Department City / State:
Hilliard, OH

WHEEL BASE: 196”

TRAVEL HEIGHT: 9’ –11”

TRAVEL LENGTH: 33’

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 10” raised roof

  • Four-Door, five-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450HP
  • Alternator: Niehoff, 360 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 2 ½” left rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlays: (2) 2” w/ 1 ½” Swivel
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • Hinged Compartment Doors
  • 4 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder racks
  • Body: S4 – Alum 43/53 Ladder Rack

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview
  • FRC Spectra Brow Light
  • Whelen Freedom LED Lightbar
  • FRC Spectra 900 Scene Lights
