Delivery Date:
08/04/2025
Department Name:
El Dorado Fire Department
Department City / State:
El Dorado, KS
Truck Type:
Dealer – Flint Hills Fire & Rescue
WHEELBASE: 220”
TRAVEL HEIGHT: 10’ – 1”
TRAVEL LENGTH: 35’ – 2”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ 15” Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 450 HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Waterous
- CSU-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (2) 2 ½” Front/ Left of Main Hosebed, (2) 2 ½” Front/ Right of Main Hosebed, (1) 1 ½” Front Bumper, 2” Plumbing, (1) 3” Deck Gun
- 1,000-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- AMDOR Roll-Up Compartment Doors, Painted
- Over 230 cu ft. Total Compartment Space
- Duo-Safety Ladder Package: 1200A 28’ 2-Section, 875-DR 16’ Roof & 10’ Folding
- Body: PA-05 RES 56/53 Elec Lad Rack, 12” D Upper Compts, Shallow Depth L2/ R2
ADDITIONAL EQUIPMENT:
- 24” Polished Stainless Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Two Cameras (Wired)
- FireTech 3-Piece 12V Brow
- Whelen Freedom IV 72” LED Lightbar
- FRC Spectra 12V Scene
- Whelen L31 Red LED
- FireTech 12V Work Light
