Delivery Date:
07/21/2025
Department Name:
Daytona Beach Shores Department of Public Safety
Department City / State:
Daytona Beach Shores, FL
Truck Type:
Dealer –South Florida Emergency Vehicles
WHEELBASE: 208”
TRAVEL HEIGHT: 9’ – 10”
TRAVEL LENGTH: 33’ – 10”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab w/ a 10-Inch Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 24,000 lbs
- Engine: Cummins X 10, 450 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 6, EVS3000
PUMP: Hale
- DSD 1500 TM Pump Module
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (2) 1 ½” to Front Bumper, 2” Plumbing, (1) 3” Deck Gun
- 750-Gallon Water Tank
BODY: Sutphen
- 3/16” Extruded Aluminum
- Mixed AMDOR Roll-Up and Hinged Compartment Doors
- Over 240 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
- Body: G9 – Alum 40/51 Ladders Thru Tank
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Channel Painted Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade, Backeye 360 HD Camera System (Wired)
- Whelen Freedom IV 72” LED Lightbar
- FRC Spectra LED Brow Lights
- FRC Spectra Tele Lights
- FRC Spectra LED Scene Lights
- Whelen Quad 600 Taillights
