Delivery Date:
02/15/2022
Department Name:
Boynton Beach Fire Rescue
Department City / State:
Boynton Beach, FL
Truck Type:
Sutphen Corporation – HS #6993
Dealer – South Florida Emergency Vehicles
WHEELBASE: 196”
TRAVEL HEIGHT: 11’ – 1”
TRAVEL LENGTH: 32’ – 9”
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Half Raised Roof
- Four-Door, Five-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9 450HP
- Alternator: Leece Neville 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½“ Right Rear, (1) 2 ½” Front/Left, (1) 2 ½”Front/Right, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
- 1000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam System: Akron 125 GPM
BODY: Sutphen
- 3/16” Extruded Aluminum
- Amdor Roll-up Compartment Doors
- Over 294 cu. ft. Total Compartment Space
- Duo-Safety Ladder Package: 24’ 2-Section, 14’ Roof & 10’ Folding
- Body: G9 – Alum 40/51 Ladder through tank
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: Brigade 360
- Whelen Freedom IV 72” LED Light Bar
- Whelen 600 LED Taillights
- HIVIZ 72” Brow Light
- Firetech 12V LED 72” Scene Lights
