Delivery Date:
04/27/2023
Department Name:
Bath Township Fire Department
Department City / State:
Akron, OH

Dealer –  Herb Fire

WHEELBASE: 208”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 33′ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” cab with 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450 HP
  • Alternator: Delco-Remy 430 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX XS-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (1) 2 ½”
  • Speedlay: (2) 2” w/ Swivels & Poly Lift-Out Trays
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Foam System: Elkhart w/ Flush

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • AMDOR Roll-Up Compartment Doors
  • 320 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: G9 – Alum 40/51 Ladder Through Tank

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade (2)
  • Deck Gun Monitor: Akron Apollo 3433 High Rise w/ Quad Stacked Tips and Stream Shaper
  • FRC Spectra Brow Light
  • Whelen Freedom LED Lightbar
  • FRC Spectra LED Telescopic Lights
  • Whelen M9 Scene Lights
