Delivery Date:
06/02/2025
Department Name:
Batesburg-Leesville Fire Department
Department City / State:
Batesburg-Leesville, SC
Truck Type:
Dealer – Williams Fire Apparatus
WHEELBASE: 186”
TRAVEL HEIGHT: 10’ – 9”
TRAVEL LENGTH: 32’
CHASSIS: Sutphen Monarch Heavy-Duty Custom Chassis, 62” Cab w/ a 10” Raised Roof
- Four-Door, Four-Person Cab
- 10” Double Frame Rails (50K PSI)
- Front Axle and Suspension 20,000 lbs w/ (4) 56” Leafs
- Rear Axle and Suspension 27,000 lbs
- Engine: Cummins L 9, 380 HP
- Alternator: Leece Neville, 320 AMP
- Transmission: Allison Gen 5, EVS3000
PUMP: Hale
- QMAX XS 1500 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 2 ½” Front Bumper, 2 ½” Plumbing, (1) 3” Deck Gun
- Crosslay: (1) 2 ½”
- Speedlays: (2) 2” w/ Swivels & Poly Lift-Out Trays
- 1000-Gallon Water Tank
- 30-Gallon Foam Tank
- Foam Educator: Akron 125 GPM
BODY: Sutphen
- 3/16” Extruded Aluminum
- Mixed Hinged and AMDOR Roll-Up Compartment Doors
- Over 290 cu ft. Total Compartment Space
- Body: G9 – Alum 40/51 Ladders Thru Tank
ADDITIONAL EQUIPMENT:
- 24” Formed Steel Bumper
- Federal Q2B Siren, Grille Mount
- Camera System: FRC, Inview Trueview, Two Cameras (Wired)
- FireTech 3-Piece 72” LED Brow Light
- Whelen Freedom IV 72” LED Light Bar
- FRC Spectra Scene Lights
- Whelen Quad 600 Taillights
