Delivery Date:
05/19/2021
Department Name:
Athens-Clarke County Fire Department, GA
Department City / State:
Athens, GA

Sutphen Corporation – HS #6809

Dealer – Williams Fire Apparatus

WHEELBASE: 196”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 32’ – 5”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QFLO-1250 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (2) 2 ½” Right, (1) 2 ½” Left Rear, (1) 3” Deck Gun
  • Crosslay: (2) 1 ½” & (1) 2 ½” w/ Swivels
  • 750-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 220 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chute with Backboard Storage
  • Body: G2 – Aluminum 40/51 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • (2) Triple Air Bottle Compartments
  • Whelen Freedom IV 72” LED Lightbar
  • Whelen Mini Freedom IV 21” LED
  • Whelen PFH2 12 Telescopic Lights
  • Whelen Traffic Advisor
  • LED RotoRay Warning Light
  • Guardian Elite FT-GESM-B Scene Lights
