More Recent Deliveries

Delivery Date:
11/16/2018
Department Name:
Beauregard Fire District #3
Department City / State:
DeRidder, LA



Sutphen Corporation

WHEEL BASE: 223”

TRAVEL HEIGHT: 9’-11 ½”

TRAVEL LENGTH: 33’-6”

CHASSIS:             Kenworth T440 – 2 Door

  • Two-Door, Two-Person Cab
  • Front Axle and Suspension: 18,000 lbs
  • Rear Axle and Suspension: 30,000 lbs
  • Engine: Cummins, PX9, 450 HP
  • Alternator: Delco, 320 AMP
  • Transmission: Allison, 3000 EVS

PUMP:                 Hale

  • QFLO-1250, Single State Pump
  • Discharge: (2) 2 ½” Left, (2) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Monitor: Akron 3423 Apollo
  • Speedlays: (2) 2” with 1 ½” Swivel
  • 1,500-Gallon Water Tank

BODY:                  Sutphen

  • Aluminum
  • Amdor Roll-Up Compartment Doors
  • 4 cu. ft. Total Compartment Space
  • Ladder Chute with Backboard Storage
  • Alco-Lite PEL-24 (24’ 2-Section and PRL-14 14’ Roof and 10’ Folding)

OPTIONAL EQUIPMENT:

  • 20” Aluminum Bumper
  • Safety Vision SV-CLCD0-70, Camera System
  • Whelen Electric Siren, Cencom Carbide
  • Whelen Freedom IV 60” LED Light Bar
  • Whelen PFP1, Brow 12V LED
