Delivery Date:
02/01/2018
Department Name:
Beesons Crossroad Fire Department
Department City / State:
Kernersville, NC

WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ 9”

TRAVEL LENGTH: 31’4”

CHASSIS:              Sutphen 62” cab with 10” half raised roof

  • Four-Door, Four-Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

PUMP:                  Hale

  • 1500 GPM Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2” Front/Left Hosebed W/Swivel, 2” Front/Right Hosebed w/Swivel, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun
  • 1000 Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • 222 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Federal Q2B
  • Generator, Smart Power, 6KW TM HYD
  • Hannay ECR-1614-17-18 Reel w/150’ 10/3
  • Undercarriage Ground Lights, LED
  • Ladder Chute w/Backboard Storage
  • Alco-Lite PEL-24
  • Booster Reel Left Section of A1 Compartment
  • Gearbox, Hale, G-Series, Rear Mounted
  • Manual Back-Up Tilt System
