Delivery Date:
10/11/2019
Department Name:
Riviera Beach Fire Department
Department City / State:
Riviera Beach, FL

Sutphen Corporation – HS #6461

WHEEL BASE: 221”

TRAVEL HEIGHT: 10′ – 9 ¼”

TRAVEL LENGTH: 43’ – 10”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Four-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension, STEERTEK 23,000 lbs
  • Rear Axle and Suspension, STEERTEK 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 1 ½” Front Bumper
  • Monitor: Elkhart (1) Vulcan Manual OS w/ 284A Stream Straightener and Quad Stacked Tips & (1) Cobra EXM DS w/ Streamshaper and Electric Nozzle
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank
  • 30-Gallon Foam Tank
  • Elkhart Foam Supply System w/ Flush

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • Hinged Compartment Doors
  • Over 192 cu. ft. Total Compartment Space
  • Duo-Safety Quint Ladder Compliment (85’: 16’ Roof, 24’ 2-Section, 35’ 3-Section & 10’ Folding)
  • SAA-4: Left High / Right Intermed / Trans

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper Extension
  • Energizer Inverter 3200 Watt Remote Start Generator
  • Federal Q2B Siren, Grille Mount
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom 4 Lightbar
  • Whelen M9V2 LED Scene/Warning Lights
  • FRC Spectra LED Brow Light
  • FRC Spectra 240V LED Scene Light
  • FireTech 12V LED Spotlights
