More Recent Deliveries

Department Name:
Netcong Fire Rescue
Department City / State:
Netcong, NJ









Sutphen Corporation

WHEEL BASE: 224”

TRAVEL HEIGHT: 9’-9 ½”

TRAVEL LENGTH: 42’-8 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville
  • Transmission: Allison Gen 5, EVS 3000

PUMP                   Hale

  • QMAX-2000 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 4” Right, (1) 2 ½” Right, (1) Front/Right of Main Hosebed
  • Monitor: (2) Elkhart 293 Manual w/ CSW Nozzle
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • 400-Gallon Water Tank

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • 75 cu. ft. Total Compartment Space
  • Duo Safety Ladders (101’; 16’R, 16’R, 24’ 2-Section, 35’ 3-Section & 10’F)
  • Left High/Right Intermed/Trans

OPTIONAL EQUIPMENT

  • 12” Bumper Extension
  • Safety Vision SV-CLCD0-70, Camera System
  • Federal Q2B
  • 6KW Harrison Generator
  • Hannay Electric Cord Reel, 150’ (1)
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom 4 Lightbar
  • FRC Spectra 12V LED Brow Light
