Delivery Date:
04/14/2019
Department Name:
Frason Global Co.
Department City / State:
Mexico City, Mexico

WHEEL BASE: 206”

TRAVEL HEIGHT: 11’ – 9 ½”

TRAVEL LENGTH: 37′ – 10 ½”

CHASSIS:             Sutphen 62”cab with flat roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 23,000 lbs.
  • Rear Axle and Suspension: 35,000 lbs.
  • Engine: Cummins ISL 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM, 6” Suction Single Stage
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
  • Crosslay: (1) 2 ½”, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
  • Monitor: Elkhart 7250 Cobra EXM with SM1500E Nozzle
  • 30-Gallon Foam Cell
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Alco-Lite Ladders (85’: 16R’, 24’ 2-Section, 35’ 3-Section & 10’ F)
  • Over 217 cu. ft. Total Compartment Space
  • Ladder Chute
  • Body SAA-RM1 Left High/ Right Sidestacker

ADDITIONAL EQUIPMENT:

  • 24” Bumper Extension
  • Federal Q2B Flush Grille Mount
  • 10KW Smart Power Generator
  • Whelen FNMINI Lightbar
  • Rigid E Series 30” LED Flood Lights
  • Tecniq ICC Lights
  • Hannay Electric Cord Reel, 200’ (1)
  • Pike Pole Storage Tubes (3)
