Custom Dry Side Tanker – Plainfield Township Volunteer Fire Company, PA

Specs

Cab
Four-door, Six-Person
10” Double Domex
Frame Rails (110K PSI)
Front Axle and Suspension
23,000 lbs w/ (4) 56” Leafs
Rear Axle and Suspension
48,000 lbs
Engine
Cummins X 12, 525 HP
Alternator
Leece Neville, 420 AMP
Transmission
Allison Gen 5, EVS4500
Pump
Hale QMAX-2000 GPM, Single Stage Pump
Discharges
(2) 2 ½” Left, (2) 4” Right, (1) 2 ½” Valve 2 ½” Pipe to Left Rear, (1) 2 ½” Front/ Left of Main Hosebed, (1) 2 ½” Front/ Right of Main Hosebed, (1) 2 ½” to Front Bumper, (1) 3” Deck Gun
Crosslays
(1) 2 ½”, 2 ½” Swivel & (2) 2” w/ 1 ½” Swivel
Water Tank
2,500-Gallon
Construction
3/16" Extruded Aluminum
Compartment Doors
Hinged
Total Compartment Space
Over 120 cu ft.
Alco-Lite Ladder Package
PEL-24 24’ 2-Section & PRL-14 14’ Roof & 10’ Folding
Body
TA-04 Tanker 56/53 High / Low
Bumper
24" Formed Steel Channel Painted Bumper
Federal Q2B
Grille Mount
Camera System
FRC, Inview 360HD w/ Built-In DVR
Intercom System
FireCom 5100D, Single Radio, 6 Position
Warning Light
Roto-Ray, LED
Lightbar
Whelen Freedom IV 72" LED
Scene Light
Whelen M6V2
Scene Light
FireTech Double Stack
Monitor
TFT XFC-52 Crossfire w/ Safety Flow w/ Quad Stack Tips & Stream Shaper
