Sutphen Custom Pumper, Demo 516, HS #7270

WHEELBASE: 196 ½”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 33′ – 0 ½”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front/Right of Main Hosebed, (1) 3” Deck Gun
  • Crosslays: (2) 2” Crosslay with 1 ½” Swivel
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Painted Roll-Up Compartment Doors
  • Over 215 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: S2 – Alum 43/53 Ladder Chute – Low Hosebed

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC, Inview Trueview, Single Camera
  • Whelen Freedom IV 72” LED Lightbar
  • Whelen L31 Rear Beacons
  • FRC Spectra 12V LED Brow Light
  • FRC 900 12V Scene Lights
