Sutphen Custom Pumper, Demo 511, HS #7119

WHEELBASE: 226 ½”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 35′ –6 ½”

CHASSIS:              Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX 1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Speedlays: (2) 2” Speedlays with Swivels
  • 750 -Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                   Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-up compartment doors with Satin Finish
  • 9 cu. ft. Total Compartment Space
  • Body: S2M (Modified) – Aluminum 43/53 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless-Steel Bumper
  • Federal Q2B Siren, Grille Mount
  • Camera System: Inview Trueview
  • Ziamatic SAC-44 Folding Wheel Chocks (Pair) MTD w/ SQCH-44H Holders
  • FRC Spectra 12V LED Brow Light
  • Whelen Freedom IV 72” LED Light Bar
  • FRC Spectra 12V Tele Lights
  • Whelen L31 Rear Beacons
