Sutphen Custom Pumper, Demo 509, HS #7098

WHEELBASE: 208”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 33′ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 420 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (2) 2” Crosslay with 1 ½” Swivel
  • 1,000 -Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Painted Roll-Up Compartment Doors
  • Over 310 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package: PEL-24 24’2-Section & PRL-14 14’ Roof & 10’ Folding
  • Body: G9 – Alum 40/51 Ladders Thru Tank

ADDITIONAL EQUIPMENT:

  • 24” Formed Steel Channel Bumper, Painted
  • Federal Q2B Siren, Grille Mount
  • Camera System: Brigade, Two Camera
  • FRC Spectra Brow Light
  • FRC Spectra Telescopic Lights
  • Whelen Freedom LED Lightbar
  • Whelen M9V Red Scene
