THIS UNIT HAS BEEN SOLD – Please call the sales office for possible new units

Sutphen Custom Pumper, Demo 485, HS #6802

WHEELBASE: 196”

TRAVEL HEIGHT: 9’ – 10”

TRAVEL LENGTH: 32′ – 9”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins L 9, 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

  • XS QMAX-1500 GPM, Single Stage Pump
  • Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Front/Left of Main Hosebed, (1) 2 ½” Front/Right of Main Hosebed, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslay: (1) 2 ½”
  • Speedlay: (2) 2” w/ Swivels & Poly Lift-Out Trays
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • Amdor Roll-Up Compartment Doors
  • Over 222 cu. ft. Total Compartment Space
  • Alco-Lite Ladder Package (10’ Folding & PRL-14 14’ Roof & PEL-24 24’ 2-Section)
  • Ladder Chute with Backboard Storage
  • Body G2-Alum 40/51 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper Extension
  • Federal Q2B Siren, Grille Mount
  • Camera System: FRC Inview Trueview
  • Whelen Freedom LED Lightbar
  • Whelen L31 Red LED Beacons
  • HiViz 72” Brow Light
  • FireTech FT-MB2.15 LED Scene Light
  • FRC Spectra 900-Q70 LED Scene Lights
