Demo 483 – SPH 100 Aerial Platform

Sutphen SPH 100, Demo 483, HS #6795

WHEEL BASE: 236”

TRAVEL HEIGHT: 11’ – 6”

TRAVEL LENGTH: 46′ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62”cab with 10” Raised Roof

• Four-Door, Six-Person Cab
• 10” Double Domex Frame Rails (110K PSI)
• Front Axle and Suspension: 23,000 lbs.
• Rear Axle and Suspension: 52,000 lbs.
• Engine: Cummins X 12, 500HP
• Alternator: Leece Neville 320 AMP
• Transmission: Allison Gen 5, EVS4000

PUMP:                  Hale

• QMAX-2000 GPM, 6” Suction Single Stage Pump
• Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
• Crosslay: (1) 2 ½” w/ 2 ½” Swivel, (2) 2” w/ 1 ½” swivel
• 300-Gallon Water Tank

BODY:                  Sutphen

• 3/16” Aluminum mounting plate
• ROM Roll-Up Compartment Doors
• 49 cu. ft. Total Compartment Space
• Alco-lite Ladders (10’ Folding & 14’ Combo & 16’ Roof & 24’ 2-Section & 35’ 2-Section)
• Ladder Chute
• Body SPH-3, left 56” high/right 56” high

ADDITIONAL EQUIPMENT:

• 12” Polished Stainless Steel Bumper Extension
• Federal Q2B Siren, Grille Mount
• 10KW Smart Power Generator
• FRC Inview Trueview Camera System
• 7 Bottle Compartments
• FRC Spectra Brow Light
• Whelen Freedom IV Lightbar
• FR Spectra 240V Scene Lights
• Whelen M6 Warning Lights
• Whelen M6V2 Warning Lights
• FR Spectra 240V Telelights
• FR Spectra 900 Scene Lights
