Demo 477 – Custom Pumper

Sutphen Custom Pumper, Demo 477, HS #6670

WHEELBASE: 196”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 33′ – 1”

CHASSIS:              Sutphen Monarch Heavy-Duty Custom Chassis, 73”cab with 10” Raised Roof

• Four-Door, Six-Person Cab
• 10” Double Frame Rails (50K PSI)
• Front Axle and Suspension: 20,000 lbs.
• Rear Axle and Suspension: 27,000 lbs.
• Engine: Cummins L 9, 450HP
• Alternator: Leece Neville 420 AMP
• Transmission: Allison Gen 5, EVS3000

PUMP:                  Hale

• QMAX-1500 GPM, Single Stage Pump
• Discharge: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
• Crosslays: (2) 1 ½” & (1) 2 ½” w/ Swivels
• 1,000-Gallon Water Tank
• 30-Gallon Foam Tank

BODY:                   Sutphen

• Amdor Roll-Up Compartment Doors
• 4 cu. ft. Total Compartment Space
• Ladder Chute w/ suction hose storage
• Body: S9 – Alum 43/53 Lad Chute Through Tank

ADDITIONAL EQUIPMENT:

• 24” Polished Stainless-Steel Bumper
• Federal Q2B Siren, Grille Mount
• Camera System: FRC Inview Trueview
• Ziamatic SAC-44 Folding Wheel Chocks (Pair) MTD w/ SQCH-44H Holders
• Whelen Freedom IV 72” LED Light Bar
• Whelen 72” 3-Piece Brow W/ ICC Lights
• Whelen 600 Warning Lights
